Bottom Diameter: φ152-178mm
Materials: Aluminum 6063-T6
Wall Thickness: 3.2-4.0mm
Surface Finish: Satin Brushed, Anodizing, Powder Coating
Flange Mount
| Item No. |  |
 |
 |
 |
 |
 |
 |
 |
| Height (m) | Bottom Dia (mm) | Top Dia (mm) | Door Dimension (mm) | Door Position (mm) | Flange Dimension (mm) | Bolt Circle (mm) | Bolt Size | |
| RJP15289A-60-BS-FG | 6 | 152 | 89 | 100x400 | 500 | 320x320 | 250 | 4xM20 |
| RJP16595A-70-BS-FG | 7 | 165 | 95 | 100x400 | 500 | 400x400 | 250 | 4xM20 |
| RJP16595A-80-BS-FG | 8 | 165 | 95 | 100x400 | 500 | 400x400 | 300 | 4xM24 |
| RJP178114A-90-BS-FG | 9 | 178 | 114 | 100x400 | 500 | 400x400 | 300 | 4xM24 |
| RJP178114A-100-BS-FG | 10 | 178 | 114 | 100x400 | 500 | 400x400 | 300 | 4xM24 |
